B601HP EVA Solar Film
- Our B601HP is an anti-PID, high-transmittance EVA encapsulation film designed to enhance PV modules’ resistance to PID degradation.
- This PV encapsulation film provides stable adhesion to glass and backsheets, along with excellent damp-heat resistance, UV resistance, and anti-PID performance.
- It also offers strong compatibility with a wide range of module materials and lamination equipment.
Get a Free Consultation
Get a Free Consultation
| Product Specifications | ||
| Specifications | Normal Specifications | Customized Specifications |
| Thickness | 0.45mm – 0.65mm | 0.2 – 0.8mm |
| Width | 1000 – 1030mm | 300 – 1300mm |
| Length | 350m | 150m/350m/400m |
|
Technical Properties |
|||
|
Performance Indicators |
Test Standard | B601HP | |
|
Using Instruction |
/ | Anti PID High Transmittance |
|
|
Shrinkage Ratio |
MD | GB/T29848 | <3.0% |
| TD | GB/T29848 | <1.5% | |
|
Light Transmittance |
280 – 380nm | Betterial | >80% |
| 380 – 110nm | GB/T29848 | >91% | |
|
Peel Strength |
EVA / Glass | GB/T29848 | >80N/cm |
| EVA / Backsheet | GB/T29848 | >80N/cm | |
|
Crosslink Degree |
GB/T29848 | >80% | |
|
Volume Resistivity |
GB/T29848 | >1*10^15Ω·cm | |
|
Damp Heat Test |
GB/T29848 | <5.0ΔYI | |
|
UV Test |
GB/T29848 | <5.0ΔYI | |
|
Anti PID Performance |
IEC62804 | <5.0% | |
| Laminating Process | ||||
| Laminated Parameters | Temperature(℃) | Vacuum Time(S) | Lamination Time(S) | |
| Single Chamber Laminator | 142 – 148 | 300 – 360 | 480 – 600 | |
| Double Chamber Laminator | Cavity 1 | 120 – 130 | 300 – 360 | 10 – 20 |
| Cavity 2 | 140 – 155 | 10 – 20 | 480 – 600 | |
